SM-X-NIM-ADPTR

Quick Spec

Parameter	Data
Product Name	NIM-4BRI-NT/TE
Ports	4-port BRI
Interface Type	Network Interface Module (NIM)
Compatibility	Cisco ISR 4000 Series
Network Protocol Support	ISDN

Product Features

• Four BRI ports for flexible connectivity.
• Supports both NT and TE modes for ISDN line.
• Integrated with Cisco's ISR 4000 series for streamlined infrastructure.
• High performance for voice and data integration.
• Easy to install and manage.

Product Applications

1. Small and medium-sized businesses looking for cost-effective voice solutions. 2. Enterprises aiming to integrate voice and data traffic. 3. Organizations requiring high-density voice connectivity for their ISR routers.

Supported Options

Accessory	Model
High-speed WAN Interface Cards	HWIC-4B-S/T
PVDM Modules	PVDM4-32
Power Supply	PWR-4450-AC

Compare to Similar Items

Model	Differences
NIM-4BRI-NT/TE	N/A - Current Product
NIM-2BRI-NT/TE	2-port BRI vs. 4-port BRI
NIM-4MFT-T1/E1	Digital voice/data module vs. BRI voice module

Quick Spec

The figure shows the appearance of NIM-2CE1T1-PRI. Table 1 shows the quick spec.

Product Number	NIM-2CE1T1-PRI
Product Description	2 port Multi-flex Trunk Voice/Channelized Data T1/E1 Module
Number of Ports	2
Dimensions (H x W x D)	1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)
Weight	0.42 lb (191g)

Supported Devices

Table 2 shows the supported devices for the NIM-2CE1T1-PRI.

Product number	Model	Description
Cisco ISR4321/K9	Cisco ISR 4321 (2GE,2NIM,4G FLASH,4G DRAM,IP Base)	50Mbps-100Mbps system throughtput, 2 WAN/LAN ports, 1 SFP port, multi-Core CPU,2 NIM, Security, Voice, WAAS, Intelligent WAN, OnePK, AVC
Cisco ISR4331/K9	Cisco ISR 4331 (2GE,2NIM,1SM,4G FLASH,4G DRAM,IP Base)	100Mbps-300Mbps system throughtput, 2 WAN/LAN ports, 2 SFP ports, multi-Core CPU,1 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
Cisco ISR4351/K9	Cisco ISR 4351 (3GE,3NIM,2SM,4G FLASH,4G DRAM,IP Base)	200Mbps-400Mbps system throughtput, 2 WAN/LAN ports, 3 SFP ports, multi-Core CPU,2 service module slots, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC
Cisco ISR4431/K9	Cisco ISR 4431 (4GE,3NIM,8G FLASH,4G DRAM,IP Base)	500Mbps-1Gbps system throughtput, 4 WAN/LAN ports, 4 SFP ports, multi-Core CPU, Dual-power, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC, separate control data and services CPUs

Compare to Similar Items

Table 3 shows the comparison between NIM-2CE1T1-PRI and NIM-8MFT-T1/E1.

Product Number	NIM-2CE1T1-PRI	NIM-8MFT-T1/E1
Product Description	2 port Multi-flex Trunk Voice/Channelized Data T1/E1 Module	8 port Multi-flex Trunk Voice/Clear-channel Data T1/E1 Module
Number of Ports	2	8
Dimensions (H x W x D)	1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)	1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)
Weight	0.42 lb (191g)	0.52 lb (236g)

Quick Specs

Table 1 shows the Quick Specs.

Product Code	SPA-1CHSTM1/OC3V2=
Product compatibility	● Cisco 7600 Series Routers ● Cisco ASR 1000 Series Routers ● Cisco ASR 9000 Series Routers
Minimum software version	● Cisco 7600 Series Routers: Cisco IOSSoftware Release 15.4(2)S and Cisco IOS XE Software Release 3.12.0.0S ● Cisco ASR 1000 Series Routers with Cisco IOS XE Software Releases 3.12.0,3.11.2,and 3.10.3 ● Cisco ASR 9000 Series Routers with Cisco IOS XR Software Release 5.2.0
Protocols	Serial encapsulations: *High-Level Data Link Control (HDLC) *Point-to-Point Protocol (PPP), RFC 1662 *Frame Relay, RFC 1490 Multilink support (bundle limit dependent on number of links per bundle; maximum of 12 links per bundle): *Multilink PPP (MLPPP), RFC 1990 *Link fragmentation and interleaving (LFI) over Frame Relay (FRF.12) and MLPPP Networking protocols: *IPv4/IPv6
Cards, ports, and slots	1 port
Reliability and availability	OIR Field-replaceable SFP optics modules Support for both 1 + 1 SONET Automatic Protection Switching (APS) and SDH Linear Multiplexer Section Protection (MSP) protocols Single SPA software reset
MIBs	RFC 2558 MIB (SONET/SDH) RFC 2495 MIB (T1/E1) RFC 2496 MIB (T3/E3)
Network management	Simple Network Management Protocol (SNMP)
Physical specifications	Weight: 0.75 lb (0.34 kg) Height: 0.8 in. (2.03 cm) Width: 6.75 in. (17.15 cm) Depth: 7.28 in. (18.49 cm)

Quick Specs

Figure 1 shows the appearance ofSPA-1XOC12-POS-V2=. Table 1 shows the Quick Specs.

Product Code	SPA-1XOC12-POS-V2=
SPA	1-Port OC-12c/STM-4 POS SPA
SIP Supported:Cisco ASR1000-SIP10	Yes
SIP Supported:Cisco ASR1000-SIP40	Yes
Number of Ports	2 (ships SPA-2XOC12-POS)
Minimum IOS XE Release	Cisco IOS XE 2.4
Minimum Hardware Revision	1.0

The Configuration

Table 2 shows the recommended elements for the SPA-1XOC12-POS-V2=.

Model	Description
SFP-OC3-LR2	OC3/STM1 SFP, Single-mode fiber, Long Reach (80km)
SFP-OC3-LR1	OC3/STM1 SFP, Single-mode fiber, Long Reach (40km)
SFP-OC12-SR	OC12/STM4 SFP, Short Reach
SFP-OC3-IR1	OC3/STM1 SFP, Single-mode fiber, Intermediate Reach
SFP-OC3-SR	OC3/STM1 SFP, Single-mode fiber, Short Reach
SFP-OC12-IR1	OC-12/ STM-4 SFP, Intermediate Reach (15km)
