SM-X-6X1G

Quick Specs

Table 1 shows the Quick Specs.

Model	NIM-1MFT-T1/E1
Serial data (channel-group*)	2 per port
E1 unframed G.703	Not supported
Voice channel associated signaling (CAS) (ds0-group)	24 per port (T1) 31 per port (E1) 1 per timeslot
PRI (pri-group*)	1 per port
Drop and insert (tdm-group)	24 per port (T1) 31 per port (E1) 1 per timeslot
Dimensions (H x W x D)	1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)

* channel-group refers to bonding of one or more time slots into a single High-Level Data Link Control (HDLC)-framed serial connection for IP data traffic connectivity. This connection is used for HDLC, Frame Relay, and Multilink PPP (MLPPP) serial WAN connections. ds0-group refers to bonding of one or more time slots into a single TDM voice connection using CAS such as ear and mouth (E&M), foreign exchange station (FXS), or foreign exchange office (FXO). This connection is used for TDM PBX or PSTN connections and typically is deployed only on T1. * pri-group refers to bonding of two or more time slots into a single TDM connection using ISDN signaling. This connection is typically used for TDM PBX or PSTN voice connections on T1 and E1, and also for data WAN connections on E1. Each call on the PRI is individually indicated as being a voice or data call with the ISDN bearer capability delivered with the call. Signaling is done on the D-channel, which is always channel 24 on a T1 and channel 31 on an E1. tdm-group refers to cross-connecting one or more time slots from one TDM interface to another. This connection is used to groom channels from different access points onto a combined T1 or E1 uplink. Because the router merely cross-connects and does not interpret or route the traffic from the ingress interface to the egress interface, the traffic type (voice and data) is transparent to the router.

Quick Specs

Figure 1 shows the appearance of PVDM4-64. Table 1 shows the Quick Specs.

Product Code	PVDM4-64
Slot	On-board motherboard or T1/E1 module slot
Description	64-channel high-density voice DSP module
Low Complexity	64
Medium Complexity	48
High Complexity	32

Compare to Similar Items

Table 2 shows the comparison of PVDM4-64, PVDM4-32 and PVDM4-128.

Product Code	PVDM4-64	PVDM4-32	PVDM4-128
Slot	On-board motherboard or T1/E1 module slot	On-board motherboard or T1/E1 module slot	On-board motherboard or T1/E1 module slot
Description	64-channel high-density voice DSP module	32-channel high-density voice DSP module	128-channel high-density voice DSP module
Low Complexity	64	32	128
Medium Complexity	48	24	96
High Complexity	32	16	64
